DJI Osmo Action 5 Pro Standard Combo

DJI Osmo Action 5 Pro Standard Combo – Technical Specifications

---

General Information

• Brand: DJI

• Model: Osmo Action 5 Pro

• Version: Standard Combo

• Type: Action Camera

• Color: Black

• Dimensions: 70.5 × 44.2 × 32.8 mm

• Weight: 146 g

• Waterproof: 20 m (without case), 60 m (with optional waterproof case)

• Certification: EN13319 (diving accessory standard)

• Warranty: 1‑Year DJI Warranty (except accessories)

• Origin: China

---

Camera & Sensor

• Sensor: 1/1.3‑inch CMOS

• Effective Resolution: 40 MP (7296 × 5472)

• Lens FOV: 155° ultra‑wide

• Aperture: f/2.8

• Focus Range: 0.35 m to infinity (fixed focus)

• Color Modes: 10‑bit D‑Log M for professional grading

---

Display

• Rear Screen: 2.5‑inch OLED touchscreen, 400 × 712 (326 PPI), 800 cd/m² typical (1000 cd/m² peak)

• Front Screen: 1.46‑inch OLED, 342 × 342 (331 PPI), 800 cd/m² typical

• **Both screens are touch‑enabled and highly visible in bright light.

---

Photo & Video Performance

• Photo Modes: Single (40 MP), Countdown, Burst (up to 30 images/3s)

• Image Format: JPEG, RAW

• Video Resolutions:

  • 4K (4:3): Up to 120 fps

  • 4K (16:9): Up to 120 fps

  • 2.7K & 1080p: Up to 240 fps (slow‑motion)

• Video Format: MP4 (HEVC / H.265)

• Max Video Bitrate: 100 Mbps

• Special Modes: SuperNight (low‑light), Subject Tracking, Timelapse, Hyperlapse

• Digital Zoom: 2x (photo & video)

---

Stabilization

• Modes: RockSteady 3.0, RockSteady 3.0+, HorizonBalancing, HorizonSteady

• **Advanced stabilization ensures ultra‑smooth footage even in high‑motion scenarios.

---

Audio

• Microphones: 3 built‑in microphones with wind noise reduction

• Audio Format: 48 kHz, 16‑bit AAC

• External Mic Support: Via USB‑C adapter (not included in standard combo)

---

Connectivity & Storage

• Connectivity: Wi‑Fi 6 (802.11 a/b/g/n/ac/ax), Bluetooth 5.1

• USB Port: 1 × USB‑C (data, charging, and accessory connection)

• Internal Storage: 47 GB

• Expandable Storage: microSD (supports up to 1 TB, U3 V30 recommended)

• File System: exFAT

---

Battery & Power

• Battery Type: Li‑ion 1S (Extreme Battery Plus)

• Capacity: 1950 mAh, 3.87 V

• Operating Time: Up to 4 hours (CIPA standard, 1080p/30fps)

• Charging Temperature: 5°C to 40°C

• Operating Temperature: -20°C to 45°C

---

Smart Features

• Pre‑Record: 5/10/15/30/60‑second buffer to capture moments before pressing record

• Subject Tracking: AI‑enabled tracking for people, vehicles, and animals

• Voice Control: Yes (via compatible app/accessories)

---

What’s in the Box (Standard Combo)

• Osmo Action 5 Pro Camera × 1

• Osmo Action Extreme Battery Plus (1950 mAh) × 1

• Horizontal‑Vertical Protective Frame × 1

• Quick‑Release Adapter Mount × 1

• Curved Adhesive Base × 1

• Locking Screw × 1

• Type‑C to Type‑C PD Cable × 1

• Rubber Lens Protector × 1

• Glass Lens Cover × 1

• Anti‑Slip Pad × 1

• DJI Logo Sticker × 1

---

Key Features

• Dual OLED Touchscreens: Bright, responsive front and rear displays.

• 1/1.3‑inch 40MP Sensor: Excellent low‑light performance and high resolution.

• 4‑Hour Battery Life: Extended runtime with the included Extreme Battery Plus.

• Advanced Stabilization: RockSteady 3.0+ and HorizonSteady for gimbal‑like smoothness.

• Pro Color & Modes: 10‑bit D‑Log M, SuperNight, and high‑frame‑rate recording.

• Modular Design: Compatible with a wide range of DJI action camera accessories.
