DJI Mic 3 (1 TX + 1 RX)

DJI Mic 3 (1 Transmitter + 1 Receiver + Charging Case) – Technical Specifications

General Information

• Model: DJI Mic 3

• Configuration: 1 Transmitter (TX) + 1 Receiver (RX) + Charging Case

• Charging Case: All‑in‑one storage, charger, and auto‑pairing hub with organized accessory compartments

• Transmitter Attachment: Magnetic & clip‑on (detachable, rotatable clip for flexible positioning)

Audio Performance & Recording

• Microphone: Built‑in omnidirectional lavalier

• Adaptive Gain Control: Automatic mode to prevent clipping; suitable for dynamic environments

• Voice Tone Presets: Three presets – Regular, Rich (emphasized lows), Bright

• Noise Cancelling: Two‑level – Basic (indoors) and Strong (noisy environments); enhanced with included windscreen

• Internal Recording (Per TX):

  • Format: Dual‑file system – Saves both original and algorithm‑enhanced versions

  • Quality: 32‑bit float uncompressed 48kHz/24‑bit audio

  • Dynamic Range: High, capturing whispers to loud sounds without distortion

• Timecode Support: Built‑in high‑precision timecode for multi‑camera sync (<1 frame drift/24 hours)

Wireless System & Transmission

• Multi‑Device Capacity: System supports up to 4 TX + 8 RX (this 1TX+1RX kit is expandable)

• Transmission Bands: Dual‑Band – 2.4 GHz & 5.8 GHz with automatic frequency hopping

• Transmission Range: Up to 400 meters (open area, unobstructed)

• Audio Transmission: Lossless Audio mode for uncompressed 48kHz/24‑bit wireless transmission

• Output Modes: Receiver supports Mono, Stereo (dual‑channel), and Quadraphonic (4‑channel output with compatible Sony cameras or software)

Receiver & Controls

• Receiver Screen: 1.1‑inch AMOLED touchscreen

• Control Interface: Touchscreen + physical dial for on‑device parameter adjustment (gain, modes, etc.)

• App Control: DJI Mimo app for advanced settings and firmware updates

Battery & Power

• Single‑Charge Runtime:

  • Transmitter: Up to 8 hours

  • Receiver: Up to 10 hours

• Total System Runtime (with Case): Up to 28 hours

• Fast Charging:

  • Quick Charge: 5 minutes → up to 2 hours of use

  • Full Charge: Approx. 50 minutes (with 3C fast charging support)

• Power‑Saving Features: Auto sleep, auto power‑off, auto on/off with camera

Connectivity & Compatibility

• Receiver Outputs: USB‑C (digital), 3.5mm TRS (analog)

• Direct Connection (OsmoAudio™): Transmitter connects directly to select DJI cameras (Osmo Action 5 Pro/4, Pocket 3, 360) without receiver

• Bluetooth: Direct‑to‑phone pairing for use with third‑party video apps

• File Export: Transfer internal recordings via charging case USB‑C cable or via DJI Mimo app

• Wide Compatibility: Works with cameras, smartphones, and computers

What’s in the Box

• DJI Mic 3 Transmitter × 1

• DJI Mic 3 Receiver × 1

• Charging Case × 1

• Windscreen × 1

• Magnetic Clip × 1

• Clip Magnet × 1

• 3.5mm TRS to TRS Cable × 1

• USB‑C Charging/Data Cable × 1

• Carrying Pouch × 1

Key Features

1. Dual‑Band 400m Transmission: Robust, long‑range, anti‑interference wireless.

2. 32‑bit Float Internal Recording: Dual‑file safety with high dynamic range.

3. 4‑Channel Output Support: Quadraphonic mode for professional multi‑track workflows.

4. Built‑In Timecode: Precise sync for multi‑camera editing.

5. Adaptive Gain & Noise Cancelling: Intelligent audio optimization.

6. 28‑Hour Total Battery: 8‑hour TX / 10‑hour RX, extendable with case.

7. Direct DJI Camera Connection: OsmoAudio™ for simplified setups.

Notes:

• System Expandable: This 1TX+1RX set can be expanded to the full 4TX+8RX system.

• Professional Features: Timecode, quadraphonic output, and 32‑bit float recording cater to professional video production.

• Ecosystem Integration: Optimized for seamless use within the DJI product lineup.
